AST-1000 (from Averna)

Summary

Tool:
AST-1000 RF Signal Tester
Short Description:

Featuring Averna’s leading RF and test expertise, the software-defined AST-1000 is powered by the NI VST and LabVIEW, and can generate all common radio signals (including AM/FM, DAB, DRM, HD Radio, and Sirius/XM), digital video signals (including ATSC, CMMB, DVB-T2, and ISDB), as well as simulate all common GNSS signals (including Galileo, GLONASS, GPS…).

And due to the AST-1000’s NI framework, customers can easily add a PXI-based waveform generator to generate any number of wireless waveforms using NI LabVIEW toolkits such as WiFi, Bluetooth, LTE, and WCDMA for module-level validation.

The AST-1000 is an extensible, future-proofed platform that can handle all of today’s infotainment RF and non-RF (e.g., CAN) test needs while also easily accommodating changing standards, new protocols and additional applications for wide-ranging product test and validation needs.

Version:
N/A
Category:
[RF Signal generator]

[Software signal generator]

[Signal recorder]

[Signal propagation simulator]

Conditions of Access:
Buy
Location:
Not fixed
Coordinates:
Not fixed
Website:
https://www.averna.com/en/products/rf-instruments/ast-1000/
Status:
Operational
How to get it:

Contact manufacturer/provider

Image:

Specifications

Supported GNSS signals:
GPS (SPS)

GPS (PPS)

GLONASS

Galileo (OS, SoL, CS)

Galileo PRS

Supported other signals:
WiFi

Other

Supported frequencies:
L1

L2

L2C

L5

E1/L1

E5a

E5b

Target users:
Technology suppliers, developers or researchers

Receiver (module or device) suppliers

Environment of uses:
Open Sky

Urban

Rural pedestrian user

Rural vehicle user

Fixed user

Aeronautical user

Contact

Provider:
Averna Technologies Inc.

87 Rue Prince, Montréal QC, Canada

https://www.averna.com/en/home/
POC Name:
sales@averna.com

Other Information

Costs:

Request for a quote

References:

Brochure available:



https://insight.averna.com/ast-1000-all-in-one-rf-signal-source-averna



To request a demo:



https://insight.averna.com/request-a-technical-demo
